Mission-Critical Data Center Solutions
Powering the Next Generation of AI Infrastructure
Engineering, manufacturing, and integrated power distribution solutions for AI, cloud, hyperscale, colocation, and enterprise data centers.
AI-Ready
POWER INFRASTRUCTUREUL / PE
ENGINEERING SUPPORTModular
SCALABLE SYSTEMS24/7
MISSION CRITICAL01
ELTRX Data Center Power Solutions
From utility service entrance to rack-level power distribution, ELTRX supports mission-critical power infrastructure.
Switchboards
UL891-focused service entrance, main-tie-main, feeders, metering, and critical distribution.
Switchgear
LV/MV switchgear integration for redundancy, protection, and maintainability.
ATS Systems
Utility/generator transfer concepts and standby power architecture.
PDU / RPP
Downstream power distribution for critical loads and flexible rack deployment.
UPS Integration
Coordination around UPS equipment, bypass, monitoring, and maintainability.
Generator Integration
Standby power interfaces, transfer logic, and control panels.
E-House
Modular electrical buildings for faster deployment and scalable capacity.
PLC / SCADA
Monitoring, alarms, dashboards, automation, and power system visibility.
02
Complete Data Center Power Architecture
Utility → MV Gear → Transformer → LV Gear → UPS → PDU/RPP → Rack.
Utility
Service Entrance
MV Gear
Protection
Transformer
Step Down
LV Gear
Main Distribution
UPS
Critical Backup
PDU / RPP
Rack Power
Rack
IT Load
03
AI & Hyperscale Ready
AI workloads push data center power density higher and require robust, scalable, digitally monitored power and cooling coordination.
Scalable distribution and capacity planning as rack loads increase.
Infrastructure planning around liquid-cooled and high-density AI environments.
PLC, SCADA, metering, alarms, analytics, and visibility.
04
Engineering Capabilities
Mechanical design, electrical engineering, automation, manufacturing support, and standards knowledge in one workflow.
Mechanical Design
Enclosures, switchboard structures, sheet metal, busbar supports, E-House coordination, and 3D CAD.
Electrical Engineering
Power distribution layouts, one-line support, breaker coordination, ATS concepts, and critical power architecture.
PE Review Available
Engineering documents can be reviewed, signed, and sealed by licensed Professional Engineers when required.
UL Knowledge
Support for UL891, UL1558, UL508A, enclosures, documentation, and compliance-focused product development.
Busbar Engineering
Copper/aluminum layouts, supports, GPO3 insulation, spacing, clearances, and thermal/mechanical review.
Manufacturing Packages
Fabrication drawings, assembly drawings, BOM, DXF, CNC files, nesting, and production-ready documentation.
05
Products Used in Data Center Projects
A focused portfolio for power rooms, electrical skids, modular buildings, and mission-critical distribution systems.
UL891 Switchboards
UL1558 Switchgear
ATS
PDU
RPP
Busway
E-House
MCC
PLC Panels
Control Panels
06
Codes, Standards & Compliance Focus
Critical infrastructure needs disciplined engineering around safety, maintainability, reliability, and documentation.
UL
NEC
NFPA
NEMA
IEEE
IEC
ANSI
CSA
ISO
07
Project Workflow
From concept to deployment with a manufacturing-ready engineering process.
Concept
Scope & Architecture
Engineering
CAD / Electrical
Review
PE / UL Focus
Manufacturing
Fabrication
FAT
Testing
Delivery
Commissioning
08
Data Center Gallery Concept
Large cinematic visuals for switchboards, E-Houses, busbars, manufacturing, FAT, and installations.
Build Your Next Data Center Power Platform with ELTRX
Mission-critical engineering, powered by technology, built for manufacturing.
